Model T-2150

Product Description
$20,606.00


***Please note: If purchased CTS, Inc. will need at least 2-4 weeks to build and prepare cooling tower for shipping and delivery.

Model T-2150

150 Nominal Tons based on design of 95/85/75 @ 446 GPM
Fan Motor 5 HP, 208-230/460V, 3PH, 60Hz
*Electrical hookups are inside the junction box located on fan motor
Cooling Capacity 2,250,000 BTU/hr
Air Volume 33,260 CFM
Water Inlet 6"
Water Outlet 6"
Tower Diameter 130"
Tower Height
90"
Operating Weight 6,181 lbs.
Dry Weight 1,377 lbs.
Flange Type Round, 150# Cast Iron


Please note: This price includes all associated freight charges within the continental United States.  Field assembly will be required and will take approximately 15-20 man hours.  If you would like a quote for CTS personnel to assemble on your job site, please request from the sales office.
