Model T-23

Name: Model T-23
Brand: Cooling Tower Systems
SKU: 89
Availability: InStock

$2,317.00

Description

*THIS COOLING TOWER WILL SHIP COMPLETELY ASSEMBLED & PACKAGED*

Engineering Information

Complete Specifications and Drawings for Model T-23

Model T-23

3 Nominal Tons based on design of 95/85/75 @ 9 GPM

Fan Motor	1/6 HP, 110/220V, 1PH, 60Hz *Electrical hookups are inside the junction box located on fan motor
Cooling Capacity	45,000 BTU/hr
Air Volume	870 CFM
Water Inlet	1.5″
Water Outlet	1.5″
Tower Diameter	27 1/8″
Tower Height	50″
Operating Weight	227 lbs.
Dry Weight	84 lbs
Nozzle Type	Round, Female (NPT) Threaded, Nylon

Shipping Weight: 100 lbs.

Shipping Dimensions: 36 x 36 x 61

Weight	200.0 lbs
