15 Ton Cooling Tower – Model T-215
The Model T-215 15 Ton Cooling Tower from Cooling Tower Systems is a durable FRP evaporative cooling tower engineered for efficient commercial and industrial cooling. Rated at 15 nominal tons based on a 95°F / 85°F / 75°F design at 44 GPM, it delivers 225,000 BTU/hr of cooling capacity with approximately 4,700 CFM of airflow. Built with corrosion-resistant fiberglass construction, the Model T-215 offers dependable performance, low maintenance, and long service life. Every unit ships fully assembled and includes complete engineering documentation, making installation fast and reliable for HVAC and industrial process cooling applications.
Key Features & Benefits
- 15 Ton Cooling Capacity
- 225,000 BTU/hr Heat Rejection
- 4,700 CFM Airflow
- Heavy-Duty FRP Construction
- Corrosion Resistant
- Ships Fully Assembled
- Low Maintenance
- Commercial & Industrial Applications
- Long Service Life
- Energy Efficient Design
Technical Specifications
15 Nominal Tons based on design of 95°F / 85°F / 75°F @ 44 GPM
| Specification | Value |
|---|---|
| Fan Motor | 1/4 HP, 110/220V, 1PH, 60Hz *Electrical hookups are inside the junction box located on fan motor |
| Cooling Capacity | 225,000 BTU/hr |
| Air Volume | 4,700 CFM |
| Water Inlet | 2″ |
| Water Outlet | 2″ |
| Tower Diameter | 46″ |
| Tower Height | 59″ |
| Operating Weight | 628 lbs. |
| Dry Weight | 154 lbs. |
| Nozzle Type | Round, Female (NPT) Threaded, Nylon |
Shipping Information
| Shipping Details | Value |
|---|---|
| Shipping Weight | 200 lbs. |
| Shipping Dimensions | 50″ × 50″ × 72″ |
| Packaging | Ships Completely Assembled & Packaged |
The Model T-215 Cooling Tower is shipped fully assembled and securely packaged to help reduce installation time and labor costs. Each unit is prepared for safe transportation and is ready for quick installation upon delivery.
Typical Applications
- Commercial HVAC Systems
- Manufacturing Facilities
- Food & Beverage Processing
- Plastic Processing Equipment
- Machine Shops
- Metal Fabrication
- Light Industrial Process Cooling
- Water-Cooled Equipment
Frequently Asked Questions
What is the cooling capacity of the Model T-215 Cooling Tower?
The Model T-215 provides a nominal cooling capacity of 15 tons with approximately 225,000 BTU/hr of heat rejection. It is rated at a design condition of 95°F / 85°F / 75°F while circulating 44 GPM.
What electrical service does the Model T-215 fan motor require?
The Model T-215 is equipped with a 1/4 HP fan motor operating on 110/220V, single-phase, 60Hz power. Electrical hookups are conveniently located inside the junction box on the fan motor.
What material is used for the Model T-215 water distribution nozzle?
The cooling tower utilizes a round, female NPT threaded nylon nozzle designed to provide dependable water distribution while offering excellent corrosion resistance and long service life.
Is the Model T-215 suitable for smaller industrial cooling systems?
Yes. With its 15-ton capacity, compact footprint, and durable FRP construction, the Model T-215 is well suited for small manufacturing operations, commercial HVAC systems, and light industrial process cooling applications.
Does the Model T-215 ship ready for installation?
Yes. Every Model T-215 Cooling Tower ships completely assembled and packaged. Engineering drawings, CAD files, assembly instructions, and operating manuals are available to support quick installation and maintenance.
