25 Ton Cooling Tower – Model T-225
The Model T-225 25 Ton Cooling Tower from Cooling Tower Systems is a durable FRP evaporative cooling tower engineered for dependable commercial and industrial cooling applications. Rated at 25 nominal tons based on a 95°F / 85°F / 75°F design at 73 GPM, it delivers approximately 375,000 BTU/hr of heat rejection with 7,000 CFM of airflow. Built with corrosion-resistant fiberglass construction, the Model T-225 provides reliable cooling performance, low maintenance requirements, and long service life. Every unit ships completely assembled and includes complete engineering documentation for quick installation and dependable operation.
Key Features & Benefits
- 25 Ton Cooling Capacity
- 375,000 BTU/hr Heat Rejection
- 7,000 CFM Airflow
- Heavy-Duty FRP Construction
- Corrosion Resistant
- Ships Fully Assembled
- Low Maintenance
- Commercial & Industrial Applications
- Long Service Life
- Energy Efficient Design
Technical Specifications
25 Nominal Tons based on design of 95°F / 85°F / 75°F @ 73 GPM
| Specification | Value |
|---|---|
| Fan Motor | 3/4 HP, 208-230/460V, 3PH, 60Hz *Electrical hookups are inside the junction box located on fan motor |
| Cooling Capacity | 375,000 BTU/hr |
| Air Volume | 7,000 CFM |
| Water Inlet | 2.5″ |
| Water Outlet | 2.5″ |
| Tower Diameter | 54 3/8″ |
| Tower Height | 70 15/16″ |
| Operating Weight | 930 lbs. |
| Dry Weight | 196 lbs. |
| Nozzle Type | Round, Female (NPT) Threaded, Nylon |
Shipping Information
| Shipping Details | Value |
|---|---|
| Shipping Weight | 295 lbs. |
| Shipping Dimensions | 64″ × 64″ × 84″ |
| Packaging | Ships Completely Assembled & Packaged |
The Model T-225 Cooling Tower is shipped fully assembled and securely packaged to reduce installation time and labor costs. Each unit is prepared for safe transportation and is ready for fast installation upon delivery.
Typical Applications
- Commercial HVAC Systems
- Manufacturing Plants
- Food & Beverage Processing
- Plastic Processing Facilities
- Chemical Processing Plants
- Machine Shops
- Metal Fabrication Operations
- Industrial Process Cooling
