Model T-2250

Product Description
$27,027.00

Model T-2250
250 Nominal Tons based on design of 95/85/75 @ 737 GPM
Fan Motor 7.5 HP, 220/440V, 3PH, 60Hz
(Also available in 208/230/460V, 3PH)
*Electrical hookups are inside the junction box located on fan motor
V-Belt Speed Reducer LBM-055C
Cooling Capacity 3,750,000 BTU/hr
Air Volume 61,270 CFM
Water Inlet 8"
Water Outlet 8"
Tower Diameter 148 3/8"
Tower Height
125 5/8"
Operating Weight 8,723 lbs.
Dry Weight 2,270 lbs.
Flange Type Round, 150# Cast Iron


Please note: This price includes all associated freight charges and complete field assembly by CTS factory personnel in the continental United States.  If you would like a formal quote, please contact our sales office.
