Model T-2300 Cooling Tower System
**Limited supplies on 3 Phase Metric Fan Motors as we upgrade to Nema Fan Motors!**

Model T-2300

Product Description
$32,555.00

Model T-2300

300 Nominal Tons based on design of 95/85/75 @ 883GPM
Fan Motor 10 HP, 208-230/460V, 3PH, 60Hz
*Electrical hookups are inside the junction box located on fan motor
Speed Reducer VBA-075-B
Cooling Capacity 4,500,000 BTU/hr
Air Volume 77,020 CFM
Water Inlet 8"
Water Outlet 8"
Tower Diameter 174 3/4"
Tower Height
131 7/8"
Operating Weight 9,213 lbs.
Dry Weight 2,828 lbs.
Flange Type Round, 150# Cast Iron


Please note:
If you would like a formal quote, please contact our sales office.
