Model T-2700

Product Description
$67,642.00
Model T-2700
700 Nominal Tons based on design of 95/85/75 @ 2,101 GPM
Fan Motor 20 HP, 220/440V, 3PH, 60Hz
(Also available in 208/230/460V, 3PH)
*Electrical hookups are inside the junction box located on fan motor
V-Belt Speed Reducer LBM-150
Cooling Capacity 10,500,000 BTU/hr
Air Volume 125,000 CFM
Water Inlet 10"
Water Outlet 10"
Tower Diameter 259 7/8"
Tower Height
181 5/16"
Operating Weight 27,895 lbs.
Dry Weight 7,863 lbs.
Flange Type Round, 150# Cast Iron


Please note: This price includes all associated freight charges and complete field assembly by CTS factory personnel in the continental United States.  If you would like a formal quote, please contact our sales office.
