Model T-2800 Cooling Tower
**Limited supplies on 3 Phase Metric Fan Motors as we upgrade to Nema Fan Motors!**

Model T-2800

Product Description
Model T-2800

800 Nominal Tons based on design of 95/85/75 @ 2,370 GPM

Fan Motor 30 HP, 208-230/460V, 3PH, 60Hz
*Electrical hookups are inside the junction box located on fan motor
Speed Reducer VBA-220-B
Cooling Capacity 12,000,000 BTU/hr
Air Volume 175,000 CFM
Water Inlet 12"
Water Outlet 12"
Tower Diameter 299 1/4"
Tower Height
194 11/16"
Operating Weight 41,349 lbs.
Dry Weight 9,656 lbs.
Flange Type Round, 150# Cast Iron

Please note:
If you would like a formal quote, please contact our sales office.
